S Communication:
Does the error code
disappear?
Power off, then restart the
unit after 2 minutes.
Measure the DC voltage between
N/L2 and S (Black pin to S , Red
pin to N/L2).
The value is fixed and
close to 0
The value is always positive
Check the wiring connection
from outdoor terminal to
outdoor PCB and wiring
between PCBs if there is
more than 1 PCB
Check if the power LED
is on?
Yes
Unplug all the high voltage
components connected to main
PCB such as 4 way valve,
heater, AC fan one by one to
check their resistance. Is there
any component short circuit?
Unplug electronic expansion valve.
Check if power LED is on?
No
Check the AC voltage of L,
N output to IPM board, is it
same as power input?
Check the DC 5V, 12V
from IPM board to main
PCB, are they normal?
Unplug all the high voltage
components connected to main
PCB such as 4 way valve, heater,
AC fan one by one to check their
resistance. Is there any component
short circuit?
No
Unplug electronic expansion
valve. Check if the DC 5V, 12V
to main PCB are OK
Replace short-circuited
component and
main PCB
Replace coil of electronic
expansion valve
Replace outdoor PCB
Replace short-circuited
component and outdoor
PCB
Yes
Yes
Yes
Yes
No
Yes
No
Replace IPM board
Repalce indoor PCB
Solved
Correct the connectio
or change wires
Check the wiring connection
between indoor and outdoor
unit, are they good?
No
Yes
For units with main PCB and IPM board both
For units with only one PCB
Note: For certain models, outdoor PCB could not be removed separately. In this case, the outdoor
electric control box should be replaced as a whole.
Replace main PCB
NO
Yes
The value is alternative
from negative to positive
Check the wiring connection
from indoor terminal to
indoor PCB, are they good?
Yes
No
No
No
To Next Page
