Ecoflam Linda+ 24 CS CPR Installation Instructions

6. TECHNICAL INFORMATION
Linda+ 24 CS CPR Linda+ 28 CS CPR
CE Certification 0694BM3465 0694BM3465
Thermal capacity max/min Kw 25.6/11.0 29,8/12,0
Thermal power max/min Kw 23.8/9.7 27,8/10,5
Efficiency at nominal thermal capacity % 92.9 93,5
Efficiency at 30% of nominal thermal capacity % 91.1 90,7
Heat loss to the shell (∆t=50°C) % 1.0 0,2
Flue heat loss with burner operating % 6.1 6,3
Flue heat loss with burner off % 0.4 0,4
Maximum discharge of fumes (methane) Kg/h 49.5 60
Residual discharge head mbar 0.96 1,60
Consumption at nominal capacity (G20) m
3
/h 2.72 3,15
(15°C, 1013 mbar) (G30-G31) Kg/h 2.02/2.00 2,34/2,31
Temp. of discharge fumes at nominal capacity with methane °C 123 123,8
CO
2
content % 7.2 6,9
Minimum ambient temperature °C+5+5
Head loss on water side (max) (∆T=20°C) mbar 200 200
Residual head of system bar 0.25 0,25
Heating temperature max/min °C 82/42 82/42
Domestic Hot Water temperature max/min °C 56/36 56/36
Quantity of hot water ∆T=25°C l/min 13.6 15.9
Quantity of hot water ∆T=35°C l/min 9.7 11.4
Minimum supply of hot water l/min 2.6 2.6
Pressure of domestic hot water max/min bar 8/0.2 8/0.2
Expansion tank capacity l 6 6
Preload pressure bar 1 1
Maximum water content in system l 130 130
Maximum heating pressure bar 3 3
Nominal pressure methane (G20) mbar 20 20
liquid gas(G30-G31) mbar 30-37 30-37
Voltage/frequency of power supply V/Hz 230 / 50 230 / 50
Total electrical power absorbed W 140 155
Protection grade of electrical system IP X4D X4D
ECOFLAM S.p.A. reserves the right to make any adjustments, without prior notice, which
it considers necessary or useful to its products, without affecting their main features.
Ecoflam S.p.A.
via Roma, 64 - 31023 RESANA (TV) - Italy - tel. 0423/715345 r.a. - telefax 0423/715444
It is recommended that the following inspections be carried out on
the boiler at least once a year:
1 - Check the seals for the water connections; replace if faulty.
2 - Check the gas seals; replace if faulty.
3 - Visual check of the entire unit and cleaning of the combustion
chamber if necessary.
4 - Visual check of the combustion chamber, and clean the burner if
needed. Removing and cleaning of the injectors if necessary.
5 - Visual check of the primary heat exchanger:
- check for overheating in the blade assembly;
- clean the exhaust fan if needed. Clean the exchanger if requied.
6 - Adjustment of the flow rate of the gas: flow rate for lighting, par-
tial load and full load.
5. MAINTENANCE
7 - Check of the heating safety systems:
- safety device for maximum temperature;
- safety device for maximum pressure.
8 - Check of the gas safety systems:
- safety device for lack of gas or flame;
- safety device for gas cock.
9 - Check of the electrical connection.
10- Check of domestic hot water production efficiency (Delivery rate
and temperature)
11- General check of the discharge of the combustion by products.
12- General check of the operation of the unit.

Ecoflam Linda+ 24 CS CPR Specifications

General

Brand	Ecoflam
Model	Linda+ 24 CS CPR
Category	Boiler
Language	English
