Ecoflam MAX GAS 70 P Manual

7
www.ecoflam-burners.com
EN
420011092300
M1 Electric motor
Y Graduated rod for head adjustment
3 Air regulation in the burner head
5 Housing
8 Blast tube
10 Socket
15 Burner flange
103B Air regulation
113 Air intake
15
MAX GAS 70 P BM2 BH50
MAX GAS Gas
RANGE NAME BY FUEL TYPE
MAX 70 70 kW
MODEL SIZE (Gas: kW; Oil: kg/h)
P 1 stage
OPERATION TYPE
BM2 BH50
MODEL
Scope of delivery
The burner is delivered in a modular system of
packagings i.e. separate set/box:
BBCH: Burner Body with Combustion Head
with flange.
- 1 bag including :- multilanguage technical manual.
- plug.
- spanner.
- screws, nuts and washer.
GT: separate Gas Train
KIT & ACS are managed and delivered separately
Contents - Burner description
113
8
M1
3
103B
Y
KIT & ACS delivered separately
5
10
