B LB 1371 Multicalor 45 ÷ 140
Parameter Display Ecoflam setting Ecoflam setting Ecoflam setting
(passive probe) (passive probe) (active probe)
QAE22 FT-TP/1000 QBE620-P...
Limit value of limit comparator AL 0 0 0
Switching differential for limit comparator HYSt 0 0 0
Proportional band Pb.1 8 8 1
Derivative time dt 20 20 3
Integral action time rt 80 80 15
Dead band (neutral zone) db 0.5 0.5 0.5
Actuator running time (sec.) tt 12 12 12
Switch-on threshold burner / stage II HYS1 -2 -2 -0.2
Switch-off level stage II HYS2 0 0 0
Upper switch-off threshold HYS3 5 5 0.5
Response threshold q 0 0 0
Heating curve slope H 2 2 2
Parallel displacement P 0 0 0
PARAMETERS LANDIS RWF 40
Parameter Display Ecoflam setting
(passive probe) (active probe)
QBE620-P...
QAE22 FT-TP/1000 -P4 -P10 -P16 -P25 -P40
Analog input 1, 2 and 3; setpoint
changeover / shift C111 9030 5030 G000 G000 G000 G000 G000
Limit comparator; controller type;
setpoint 1; locking C112 0010 0010 0010 0010 0010 0010 0010
Unit address; decimal place / unit,
signal for out-of-range C113 0110 0110 0110 0110 0110 0110 0110
Measured value range start analog
input 1 SCL 0 0 0 0 0 0 0
Measured value range
analog input 1 SCH 100 100 4 10 16 25 40
Measured value range
analog input 2 SCL2 0 0 0 0 0 0 0
Measured value range
analog input 2 SCH2 0 0 0 0 0 0 0
Lower setpoint limit SPL 60 60 0 0 0 0 0
Upper setpoint limit SPH 88 88 4 10 16 25 40
Actual value correction,analog input 1 OFF1 0 0 0 0 0 0 0
Actual value correction,analog input 2 OFF2 0 0 0 0 0 0 0
Actual value correction,analog input 3 OFF3 0 0 0 0 0 0 0
Filter time constant for digital filter, dF1 1 1 0 0 0 0 0
analog input 1
CONFIGURATION LANDIS RWF 40
