Ecoflam Multicalor 45 - Multicalor 45 Parts List (Continued)

pag.40
B LB 1371 Multicalor 45 ÷ 140
TC = SHORT HEAD TL = LONG HEAD
Multicalor 45
N° DESCRIPTION
code
1-AIR PRESSURE SWITCH DUNGS LGW10 A2P Q120
2-AIR INTAKE SET GRPA100
3-PLUG WIELAND 6 pin E226
4 -
COVER
BFC09151/011
5- GLASS BFC02004
6-VIEWING WINDOW BFC02006
7- MOTOR
550 W M169
8-FAN
220 x 98 BFV10155/001
9-AIR CONVEYOR BFC08202/017
10 - FAN SCOOP BFC08055/001
11 - AIR INTAKE BFC04160/011
12 - ADAPTER LANDIS AGQ1.1A27 E1202/11
13 - CONTROL BOX BASE LANDIS A402
SATRONIC A417
14 - CONTROL BOX LANDIS LGB22 A130/1
LANDIS LMG 22 A153/2
SATRONIC DMG 972 A162/01
15 - IGNITION TRANSFORMER
COFI 1020 CM
T105/1
16 - REMOTE CONTROL SWITCH MC9.10 R603/1
17 - REMOTE CONTROL SWITCH (PUMP) MC9.10 R603/1
18 - MOTOR THERMAL RELAY Lovato RF9 1,4-2 R510
19 - MAIN SWITCH
cod.40100I1509 R1020
20 - HIGH/LOW/AUTO FLAME
SELECTOR
R1020/5
21 -
GAS/LIGHT-OIL SELECTOR
R1020/5
22 - LAMP
EL/N-SC4 Elettrospring E1510
23 - FUSE SUPPORT FUSIT FH-B528 E802/2
24 - RELAY BASE FINDER 5534 R906
25 - RELAY FINDER 5534 R712
26 - ANTIJAMMING FILTER S132/4
27 - IGNITION CABLE TC BFE01402/1
TL BFE01402/2
28 - UV CELL LANDIS QRA2 A205
29 - IGNITION ELECTRODES SET GREL106
30 - PIPE BFT13102/001
31 - ROD BFA08001/001
32 - FIRING HEAD TC
BFT13101/101
TL
BFT13101/201
33 - REAR DISC
BFD02010/401
34 - FRONT DISC
BFD07014
35 - NOZZLE HOLDER
BFC11052
36 - INNER ASSEMBLY TC
GRTT0100/725
TL
GRTT0100/726
37 - BLAST TUBE TC
BFB04005/103
TL
BFB04005/203
38 - GASKET BFG03002/1
39 - AIR DAMPER MOTOR LANDIS SQN 30.251A2700 M212
40 - OIL PUMP
SUNTEC AN 67 C P113
41 - COUPLING MP501/3
42 -
NIPPLE
TN 6x1500
S923/2
43 - HOSES TN 10X1200
S905
44 - OIL FILTER art. 70301-01P S117/1
45 - PUMP MOTOR
200 W M111/1
46 - CONDENSATOR 6.3 µF C107/3
47 - OIL VALVE DELTA 1/8 F.84 V420
48 - COIL DELTA V502/2
49 - OIL VALVE PARKER SCEM VE131 V175/2
50 - COIL PARKER V516
51 - SILENCER (Opzionale) GRSIL02
52 - MODULATING UNIT
LANDIS RWF 40 E1215
