Ecoflam Multicalor 45 - Multicalor 120 & 140 Parts List (Continued)

pag.44
B LB 1371 Multicalor 45 ÷ 140
Multicalor 120 Multicalor 140
N° DESCRIPTION
code code
1-AIR PRESSURE SWITCH DUNGS LGW10 A2P Q120 Q120
2-AIR INTAKE SET GRPA100 GRPA100
3-PLUG WIELAND 6 pin E226 E226
4 - BURNER COVER BFC09151/011 BFC09151/011
5- GLASS BFC02004 BFC02004
6-VIEWING WINDOW BFC02006 BFC02006
7- MOTOR
2200 W M167 M167
8-FAN
260 x 110 BFV10151/001 BFV10151/001
9-AIR CONVEYOR BFC08201/017 BFC08201/017
10 - FAN SCOOP BFC08051/001 BFC08051/001
11 - AIR INTAKE BFC04160/011 BFC04160/011
12 - ADAPTER LANDIS AGQ1.1A27 E1202/11 E1202/11
13 - CONTROL BOX BASE LANDIS A402 A402
SATRONIC A417 A417
14 - CONTROL BOX LANDIS LGB22 A130/1 A130/1
LANDIS LMG 22 A153/2 A153/2
SATRONIC DMG 972 A162/01 A162/01
15 - IGNITION TRANSFORMER
COFI 1020 CM
T105/1 T105/1
16 - REMOTE CONTROL SWITCH
BF16.10 R617/1 R617/1
17 - REMOTE CONTROL SWITCH (PUMP) MC9.10 R603/1 R603/1
18 - MOTOR THERMAL RELAY Lovato RF25 4,5. 7,5A R513/2 R513/2
19 - MAIN SWITCH
cod.40100I1509 R1020 R1020
20 - HIGH-LOW FLAME SWITCH cod.360000001 R1020/1 R1020/1
21 -
GAS/LIGHT-OIL SELECTOR
R1020/5 R1020/5
22 - LAMP
EL/N-SC4 Elettrospring E1510 E1510
23 - FUSE SUPPORT FUSIT FH-B528 E802/2 E802/2
24 - RELAY BASE FINDER 5534 R906 R906
25 - RELAY FINDER 5534 R712 R712
26 - ANTIJAMMING FILTER S132/4 S132/4
27 - IGNITION CABLE TC BFE01402/1 BFE01402/1
TL BFE01402/3 BFE01402/3
28 - UV CELL LANDIS QRA2 A205 A205
29 - IGNITION ELECTRODES SET GREL106 GREL106
30 - PIPE
BFT13110/101 BFT13110/101
31 - ROD BFA08001/001 BFA08001/001
32 - FIRING HEAD TC
BFT13110/101 BFT13110/101
TL
BFT13110/201 BFT13110/201
33 -
DISC ASSEMBLY
GRDIF10 GRDIF10
34 - FRONT DISC - -
35 - NOZZLE HOLDER
BFC11052 BFC11052
36 - INNER ASSEMBLY TC
GRTT0100/741 GRTT0100/741
TL
GRTT0100/742 GRTT0100/742
37 - BLAST TUBE TC
BFB06004/103 BFB06004/121
TL
BFB06004/221 BFB06004/221
38 - GASKET
BFG03002/4 BFG03002/4
39 - AIR DAMPER MOTOR LANDIS SQN 30.251A2700 M212 M212
40 - OIL PUMP
DANFOSS RSA 125 P117 P117
41 - COUPLING MP501/7 MP501/7
42 -
NIPPLE
TN 6x1500
S923/2 S923/2
43 - HOSES TN 14x1200 S903/2 S903/2
44 - OIL FILTER art. 70301-01P S117/1 S117/1
45 - PUMP MOTOR 370 W M119/2 M119/2
46 - CONDENSATOR
14 µF C107/5 C107/5
47 - OIL VALVE DELTA 1/8 F.84 V420 V420
48 - COIL DELTA V502/2 V502/2
49 - OIL VALVE PARKER SCEM VE131 V175/2 V175/2
50 - COIL PARKER V516 V516
51 - SILENCER (OPTION) GRSIL02 GRSIL02
52 - MODULATING UNIT
LANDIS RWF 40 E1215 E1215
TC = SHORT HEAD TL = LONG HEAD
