Preparations
1.
Open dispenser with key (see
Ä
Chapter 3 ‘Scope of delivery’ on page 17).
Fig. 2: Peristaltic pump
2. Label the pump with the installation date (Pos. 1).
Fig. 3: Insert batteries (4 x AA Mignon LR6)
3. The batteries are already inserted by the factory.
If this is not the case, proceed as follows:
n Open battery compartment (Pos. 2).
n Insert four new 1.5 V AA Mignon LR6 batteries (item 3), making sure the polarity
is correct (see imprint in the battery compartment lid).
n Close battery compartment (Pos. 2).
4. Remove the key.
5. Close dispenser.
Preparing for dosing
1. Hold one hand (or both hands) in the sensor area.
The sensitive range is factory set at the centre of the dispenser.
For setting see:
Ä
‘Set dosing level (dosing quantity):’ on page 27
2. Remove hand and hold in sensor area once again.
ð
The dispenser doses again.
ð
After two or three doses, the pump is filled and the dispenser is ready for use.
Commissioning
26MAN048961, Rev. 2-09.2020
