Details for setup
Data Value Unit
Width 545 mm
Depth 520 mm
Height 1000 mm
Weight (approx.) 22 - 25 kg
Temperature 10-40 °C
6.3 Mechanical connections
5 l/h 11 l/h 30 l/h 50 l/h 120 l/h Einheit
Suction connection of the pump 6,4/9,6 6,4/9,6 12,7/19,1 12,7/19,1 12,7/19,1 mm
Outlet service valve on discharge side 4/6 4/6 6/8 8/12 12/16 mm
Overflow side multi-function valve 4/6 4/6 6/8 6/8 12/21 mm
6.4 Electrical connection work and supply
CAUTION!
Before you put the metering station into operation, you must check the
existing power supply
. The power supply must conform to the specifications
on the type plate and in the circuit diagram.
See type plate on the metering station (
Ä Chapter 6.1 ‘Product
identification and order number’ on page 54 and
Ä Chapter 1.6 ‘Product
designation / type plate’ on page 13)
Data Value Unit
Supply voltage (±10%) 100-240 V
Mains frequency 50 / 60 Hz
Power intake at metering capacity: 11 l/h max. 0.15 A
Power intake at metering capacity: 50 l/h max. 0.35 A
Motor output at metering capacity: 5, 11, 30 l/h 30 W
Motor output at metering capacity: 50, 120 l/h 50 W
Fuse value (slow-blowing) 8 A
Protection rating IP 65
Protection class (without PE) II
6.5 Component data
See Main Operating Instructions 417101649 Dosing station ECO, Ä Table on page 3.
Technical data
55 417101656 Rev. 01-10.2019
