3 Delivery (Standard ECO metering station)
The Standard Eco dosing station consists of the following sections:
n Intake
n Metering
n Delivery
The components of the standard delivery (without accessories) are listed in the table
below
. For further information, refer to the main operating manual (417101649 Dosing
station ECO,
Ä
Table on page 3).
Figure Description
Basic metering station (minimal configuration)
"Flushing valves" option for suction-side connection!
"Changeover valves" option for suction-side connection
"Changeover valves with pilot valves and Dual Level Control 115V or
240V" option for suction-side connection "Dual Level Control operating
instructions"
Maintenance valve appendix
EcoPro diaphragm metering pump
Delivery (Standard ECO metering station)
30417101656 Rev. 01-10.2019
