9 Technical Data
Data Value Unit
Valve size II G 5/8“
Over pressure function (1-5) 0,1 – 0,5 (1 - 5) MPa (bar)
Over pressure function (1-5) - manufacturing
adjustment
0,5 (5) + 20 % MPa (bar)
Over pressure function (5-8) 0,5 – 1 (5 - 8) MPa (bar)
Over pressure function (5-8) - manufacturing
adjustment
0,8 (8) + 20 % MPa (bar)
Pressure maintenance function 0,05 - 0,1 (0,5 -1) MPa (bar)
Flow max l/h 54 l/h
Input side connection (PE and PTFE) ID/AD 4/6
Output side connection */** (PE and PTFE) ID/AD 6/8
Return connection ID/AD 6/12
Cross section of return line min. NW 6
We reserve the right to make technical modifications since our products are
constantly upgraded.
* The maximum permitted pressure range must be respected in the
metering lines!
** Connection sizes on request.
9.1 Parts which come in contact with the metering product:
Data Value Unit
Valve unit PVDF, P
Diaphragm (compound diaphragm) PTFE-EPDM
O-rings FPM, EPDM
Technical Data
30417101224 Rev. 05-05.2019
