INSTRUCTIONS MANUAL
-17-
+
+
+
+
+
+
FIG.4b
6
7
+
Refer to Fig.4b.
6. Rear body shell
Disassembly: Remove rear bottom door, then screw off 6 screws marked (+)
7. Left side body shell
Disassembly: Remove frontal and rear body shell, then screw off 10 screws
marked (+)
