INSTRUCTIONS MANUAL
-22-
BASIC COMPONENTS
Refer to Fig.7, Fig.8, Fig.9, Fig.10:
a) USB port
b) ---
c) Main switch
d) Fuse
e) Socket for electrical supply plug
f) Sanitizer socket (*)
g) ---
h) Ventilation grid
i) UV cartridge (*)
j) New oil cartridge (*)
k) New Oil / UV scale
l) Used oil scale
m) Condenser + Fan
n) Front swirling wheel
o) Manifold
p) Capsizable control panel
q) Power supply filter
r) Oil pump filling cap
s) Refrigerant bottle lock knob
t) Rear wheel
u) New oil container (*)
v) Used oil container
w) UV container (*)
x) External analyzer connection (*)
y) 5V Power supply
z) Dryer filter
1) Vacuum pump
2) Compressor
3) LP service hose outlet
4) HP service hose outlet
5) LP quick connection
6) HP quick connection
7) Handle
8) ----
9) Motherboard
10) Backup container (*)
(*) if installed, depending on machine model
