INSTRUCTIONS MANUAL
-16-
+
+
+
+
+
+
FIG. 4a
4
2
3
1
5
THE MACHINE
PLASTIC COVER
Refer to Fig.4a .
1. Upper plastic body
2. Frontal body shell
Disassembly: Screw off 6 screws marked (+)
3. Right side body shell
Disassembly: Remove frontal and rear body shell, both right doors and then
screw off 8 screws marked (+)
4. Right upper door
5. Right bottom door
Disassembly: Screw off 2 screws marked (+)
