CONTROLS AND CONTROL SYSTEM
(A1) High pressure gauge for A/C system
(A2) Low pressure gauge for A/C system
(A4) Pressure gauge for bottle refrigerant pressure
(A6) Emergency/alarms panel
(A7) Display
(A8) Pushbuttons for modifying and starting/stopping operations
(A9) Operations selector panel
A1
A2
A9
A4
A6
A7
A8
