ECOVACS Deebot 6 - Quick Start

EN
8
3. Operating and Programming
3.2 Quick Start
Charging Dock Placement
Install Side Brush
Power ON
Assemble Charging Dock: Insert the
Charging Dock Top Lid into the slot on the
Charging Dock Base. Slide the Lock/Release
button on the back of the Charging Dock to
the left to lock the Top Lid in place.
Placement: Place the Charging Dock on a
level oor surface against the wall with the
base perpendicular to the ground. Keep
the immediate area 1.5m (5') in front of the
charger and 0.5m (1.6') on both sides of
the charger clear of objects and reective
surfaces.
Plug the Charging Dock in.
Attach the Side Brush to the bottom of
DEEBOT 6 by pressing the brush into the slot
until it clicks.
Turn the robot’s Bottom Power Switch to
the ON position. “I” indicates ON and “O”
indicates OFF.
1
2
3
When DEEBOT 6 is not working, it is
suggested to keep it powered ON and
charging, instead of powered OFF.
*
0.5m (1.6')
0.5m (1.6')
1.5m (5')
ON
