EcoWater ECWS - Page 25

25
ECOWATER
SYSTEMS
Repair Parts
ECOWATER SYSTEMS CENTRAL WATER FILTER ASSEMBLY
Key
No.
Part No. Description
1 7170296 O-Ring, 2-7/8” x 3-1/4”
2 7170254 O-Ring, 13/16” x 1-1/16”
3 7077870 Top Distributor
4 7265025 Filter Screen
5 7170270 O-Ring, 2-3/4” x 3”
6 7105047 Repl. Bottom Distributor
7 7088033 Retainer Clip (2 req.)
8 7176292 Clamp Section (2 req.)
9 7304235 Repl. Mineral Tank, 8” x 35”
10 7301619 Activated Carbon, 30 lbs. (12 lbs. req.)
11 0501783 Filter Sand, 10 lbs. (5 lbs. req.)
12 7124415 Gravel, 17 lbs. (6 lbs. req.)
13 7210478 Cover
14 7210509 Faceplate (order decal below)
- 7308970 Faceplate Decal
15 7308938 Repl. Electronic Control Board (PWA)
16 7275907 Transformer
17 7211173 Support, Faceplate
18 7274286 Rim
19 7218638 Outer Shroud Tank
20 7248706 Ground Clamp Kit
21 7214383
Bypass Valve 
22 7112882
Hose Clamp 
23 7108118
Drain Hose, 1/2” I.D. 
24 1103200
Adaptor Elbow 
 Not included
