EcoWater ETF EIV-10 - Page 19

19
ECOWATER
S Y S T E M S
Repair Parts
Key
No.
Part No. Description
50 7224087 Screw, #8-32 x 1” (2 req.)
51 7286039 Motor (incl. 2 ea. of Key No. 50)
52 7231393 Motor Plate
53 0900857 Screw, #6-20 x 3/8” (3 req.)
54 7171250 Bearing
55 7335024 Cam & Gear
56 7169180 Clip, Drain
57 7172793 Drain Hose Adaptor
58
7170288 O-Ring, 15/16” x 1-3/16”, single
7336402 O-Ring, 15/16” x 1-3/16”, pack of 20
59
7178202
Flow Plug, 7 gpm,
Models ETF AIV-10 & ETF EIV-10
7178210
Flow Plug, 10 gpm,
Models ETF AIV-12 & ETF EIV-12
– 7185487 Seal Kit (includes Key Nos. 60-65)
60
á
O-Ring, 5/8” x 13/16”
61
á
O-Ring, 1-1/8” x 1-1/2”
62
á
O-Ring, 4-1/2” x 4-7/8”
63
á
Rotor Seal
64
á
Seal
65
á
Seal, Nozzle & Venturi
66 7174313 Bearing, Wave Washer
67 7335058 Rotor & Disc
68 7171187 Plug, Drain Seal
69 7129889 Spring
70
7089306 Clip, 1”, single (2 req.)
7336428 Clip, 1”, pack of 20
71
7077642 Copper Tube, 1”, single (2 req.)
7344138
Copper Tube, 1”, pack of 10
(includes 10 ea. of Key No. 72)
Key
No.
Part No. Description
72
7311127
O-Ring, 1-1/16” x 1-5/16”,
single (2 req.)
7336410
O-Ring, 1-1/16” x 1-5/16”,
pack of 20
73 7343873 Inlet Check Valve w/O-Ring
74 7078240 Turbine Support & Shaft
75 7081201 Retainer, Nozzle & Venturi
76 7171145 Valve Body
77 7170319 O-Ring, 1/4” x 3/8” (2 req.)
78 7336208 Air Inlet Screen
79 7336193 Aspirator Check Valve
80 7120526 Elbow, 90°
81 7292323 O-Ring, 3/16” x 7/16”
– 7085247
Nozzle & Venturi Assembly
(includes Key Nos. 82-88)
82 7081104 Housing, Nozzle & Venturi
83 1148800 Flow Plug, .3 gpm
84
7114533 Nozzle & Venturi Kit w/Gasket
7204362 Gasket only, single
7336486 Gasket only, pack of 20
85 7146043 Screen
86 7167659 Screen Support
87
7170262 O-Ring, 1-1/8” x 1-3/8”, single
7336436 O-Ring, 1-1/8” x 1-3/8”, pack of 20
88 7199729 Cap
89 7175199 Wave Washer
90 7171161 Valve Cover
91 7172997 Screw, #10 x 2-5/8” (8 req.)
92 7305150 Switch
93 7140738 Screw, #4-24 x 3/4” (2 req.)
94 7214383
Bypass Valve, 1” Ù (includes 2 ea.
of Key Nos. 70 & 72)
To order parts, call your local EcoWater dealer or go to
www.ecowater.com to locate a dealer in your area.
Ù
Optional parts, not included with filter
VALVE PARTS LIST
