EcoWater ETF2300AIV10 - Repair Parts; Valve Parts List

35
ECOWATER
S Y S T E M S
Repair Parts
Key
No.
Part No. Description
50 7224087 Screw, #8-32 x 1” (2 req.)
51 7286039 Motor (incl. 2 ea. of Key No. 50)
52 7231393 Motor Plate
53 0900857 Screw, #6-20 x 3/8” (3 req.)
54 7171250 Bearing
55 7335024 Cam & Gear
56 7169180 Clip, Drain
57 7172793 Drain Hose Adaptor
58
7170288 O-Ring, 15/16” x 1-3/16”, single
7336402 O-Ring, 15/16” x 1-3/16”, pack of 20
59
7178202
Flow Plug, 7 gpm,
ETF2300AIV10 & ETF2300EIV10
7178210
Flow Plug, 10 gpm,
ETF2300AIV12 & ETF2300EIV12
– 7185487 Seal Kit (includes Key Nos. 60-65)
60
á
O-Ring, 5/8” x 13/16”
61
á
O-Ring, 1-1/8” x 1-1/2”
62
á
O-Ring, 4-1/2” x 4-7/8”
63
á
Rotor Seal
64
á
Seal
65
á
Seal, Nozzle & Venturi
66 7174313 Bearing, Wave Washer
67 7335058 Rotor & Disc
68 7171187 Plug, Drain Seal
69 7129889 Spring
70
7089306 Clip, 1”, single (2 req.)
7336428 Clip, 1”, pack of 20
71
7077642 Copper Tube, 1”, single (2 req.)
7344138
Copper Tube, 1”, pack of 10
(includes 10 ea. of Key No. 72)
72
7311127
O-Ring, 1-1/16” x 1-5/16”,
single (2 req.)
7336410
O-Ring, 1-1/16” x 1-5/16”,
pack of 20
Key
N
o.
Part No. Description
73 7343873 Inlet Check Valve w/O-Ring
– 7331703
Turbine & Support Assembly,
including 2 O-Rings (See Key No.
72) & 1 ea. of Key Nos. 74 & 75
74
á
Turbine Support & Shaft
75
á
Turbine
76 7081201 Retainer, Nozzle & Venturi
77 7171145 Valve Body
78 7170319 O-Ring, 1/4” x 3/8” (2 req.)
79 7336208 Air Inlet Screen
80 7336193 Aspirator Check Valve
81 7120526 Elbow, 90°
82 7292323 O-Ring, 3/16” x 7/16”
– 7085247
Nozzle & Venturi Assembly
(includes Key Nos. 83-89)
83 7081104 Housing, Nozzle & Venturi
84 1148800 Flow Plug, .3 gpm
85
7114533 Nozzle & Venturi Kit w/Gasket
7204362 Gasket only, single
7336486 Gasket only, pack of 20
86 7146043 Screen
87 7167659 Screen Support
88
7170262 O-Ring, 1-1/8” x 1-3/8”, single
7336436 O-Ring, 1-1/8” x 1-3/8”, pack of 20
89 7199729 Cap
90 7175199 Wave Washer
91 7171161 Valve Cover
92 7172997 Screw, #10 x 2-5/8” (8 req.)
93 7305150 Switch
94 7140738 Screw, #4-24 x 3/4” (2 req.)
95 7214383
Bypass Valve, 1” Ù (includes 2 ea.
of Key Nos. 70 & 72)
To order parts, call your local EcoWater dealer or go to
www.ecowater.com to locate a dealer in your area.
Ù
Not included with filter.
VALVE PARTS LIST
