ECOWITT WN1900 - Install Wind Speed; Install Rain Gauge

8
Figure 4: Wind vane installation diagram
5.2.3 Install wind speed
Push the wind speed cups into the shaft as shown in figure 5.
Tighten the set screw with screw driver. Make sure the wind speed cups can
spin freely.
Figure 5: Wind speed cup installation diagram
5.2.4 Install Rain Gauge
Install the rain gauge funnel. Rotate clockwise to attach the funnel to the
outdoor sensor.
