Motherboard User’s Guide
Integrated Peripherals Page
These options display items that define the operation of peripheral
components on the system’s input/output ports.
Phonex-AwardBIOS CMOS Setup Utility
Integrated Peripherals
Help Item
f
f
f
f
Menu Level
f
IDE Function Setup [Press Enter]
RAID Config [Press Enter]
Onboard Device Setup [Press Enter]
Super IO Device [Press Enter]
: Move Enter: Select +/-/: Value F10: Save Esc: Exit
F1: General Help F5: Previous Values F6: Fial-Safe Defaults F7: Optimized Defaults
On-Chip IDE Channel 0
Use these items to enable or disable the PCI IDE channels that are integrated on the
motherboard.
Primary Master/Slave PIO
Each IDE channel supports a master device and a slave device. These four items let
you assign the kind of PIO (Programmed Input/Output) was used by the IDE
devices. Choose Auto to let the system auto detect which PIO mode is best, or
select a PIO mode from 0-4.
IDE Function Setup (Press Enter)
Scroll to this item and press <Enter> to view the following screen:
X
Phonex-AwardBIOS CMOS Setup Utility
IDE Function Setup
Help Item
Menu Level
f
OnChip IDE Channel 0 [Enabled]
Primary Master PIO [Auto]
Primary Slave PIO [Auto]
Primary Maste UDMA [Auto]
Primary Slave UDMA [Auto]
Secondary Master UDMA [Auto]
Secondary Slave UDMA [Auto]
IDE DMA transfer access [Enabled]
Serial-ATA Controller [All Enabled]
IDE Prefetch Mode [Enabled]
IDE HDD Block Mode [Enabled]
: Move Enter: Select +/-/: Value F10: Save Esc: Exit
F1: General Help F5: Previous Values F6: Fial-Safe Defaults F7: Optimized Defaults
