Onboard Device Setup (Press Enter)
Scroll to this item and press <Enter> to view the following screen:
X
Phonex-AwardBIOS CMOS Setup Utility
Onboard Device Setup
Help Item
Menu Level
f
Onchip USB [V1.1 + V2.0]
USB Memory Type [SHADOW]
USB Keyboard Support [Enabled]
USB Mouse Support [Enabled]
HD Audio [Auto]
Onboard Lan [Enabled]
Onboard Lan Boot ROM [Enabled]
MAC Media Interface [Pin Strap]
Machine MAC(NV) Adress [Press Enter]
x
f
Onchip USB
This item enables users to enable or disable the onchip USB function, setting it to
be USB1.1 or USB2.0 compatible.
F5:Previous Values F6: Fail-Safe Defaults F7:Optimized Defaults
MAC Media Interface
This item is used to select MAC Media interface.
Machine MAC(NV) Adress
Enable this field to enter the MAC(NV) address in the field below.
USB Mouse Support
Enable this item if you plan to use a mouse connected through the USB port in a
legacy operating system (such as DOS) that does not support Plug and Play.
HD Audio
Enables and disables the onboard audio chip. Disable this item if you are going to
install a PCI audio add-in card.
Onboard Lan
Enables or disables the Onboard Lan.
USB Memory Type
This item indicates the USB memory type.
USB Keyboard Support
Enable this item if you plan to use a keyboard connected through the USB port in
a legacy operating system (such as DOS) that does not support Plug and Play.
Onboard Lan Boot ROM
This item enables or disables LAN Boot ROM.
: Move Enter: Select +/-/: Value F10: Save Esc: Exit
F1: General Help F5: Previous Values F6: Fial-Safe Defaults F7: Optimized Defaults
Press <Esc> to return to the Integrated Peripherals page.
