Chapter 3: BIOS Setup Utility
PC Health Status Page
On motherboards that support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Phonex-AwardBIOS CMOS Setup Utility
PC Health Status
Help Item
Menu Level
f
: Move Enter: Select +/-/: Value F10: Save Esc: Exit
F1: General Help F5: Previous Values F6: Fial-Safe Defaults F7: Optimized Defaults
Smart Fan Function [Press Enter]
Shutdown Temperature [Disabled]
Warning Temperature [Disabled]
CPU Tcontrol 24°C
System Temperature 29°C
CPU Fan Speed 2518 RPM
System Fan Speed 0 RPM
CPU Vcore 1.36V
VDIMM 1.79V
Phoenix-Award WorkstationBIOS CMOS Setup Utility
Smart Fan Function
f Smart Fan Function (Press Enter)
Scroll to this item and press <Enter> to view the following screen:
Item Help
ff
Menu Level
CPU Smart Fan Function [Disabled]
CPU FAN Low PWM 0
CPU FAN Temp of Low PWM 0
CPU FAN Slope(PWM/
o
C) 0
CPU SMART FAN Delta T 0
X
X
X
X
These items enable you to define the CPU/System temperatur by smartly adjusting
the CPU/System fan. When it is set at certain temperature, the CPU/SYS Fan
PWM value will change accordingly.
CPU/SYS Smart Fan Function
mnlk
F5:Previous Values F6: Fail-Safe Defaults F7:Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
Press <Esc> to return to the main menu setting page.
