Chapter 3
BSWI-D2 USER MANUAL
35
+/- :Change Opt.
Enter : Select
F1:General Help
Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version 2.17.1249. Copyright (C) 2015 American Megatrends, Inc.
Serial Port 1 Configuration
Serial Port [Enabled]
Device Settings IO=3F8h; IRQ=4;
Change Settings [Auto]
Enable or Disable Serial Port
(COM)
Super IO Configuration
Use this item to show the information of Super IO configuration.
Serial Port 1 Configuration
Scroll to this item and press <Enter> and view the following screen.
Serial Port (Enabled)
This item allows you to enable or disable serial port.
Device Settings (IO=3F8h; IRQ=4)
This item shows the information of the device settings.
Change Settings (Auto)
Use this item to change device settings.
Press <Esc> to return to the Super IO Configuration page.
Super IO Chip (IT8625)
This item shows the information of the super IO chip.
+/- :Change Opt.
Enter : Select
F1:General Help
Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.
:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version 2.17.1249. Copyright (C) 2015 American Megatrends, Inc.
Main Advanced Chipset M.I.B X Boot Security Exit
Super IO Configuration
Super IO Chip IT8625
Serial Port 1 Configuration
Serial Port 2 Configuration
Parallel Port Configuration
Set Parameters of Serial Port
1 (COMA)
Main Advanced Chipset M.I.B X Boot Security Exit
To Next Page
