1
BSWI-D2 USER MANUAL
Chapter 1
Chapter 1
Introducing the Motherboard
Introduction
Thank you for choosing the BSWI-D2 motherboard. This motherboard is a high
performance, enhanced function. This motherboard has onboard Intel
®
Braswell
SoC for high-end business or personal desktop markets.
It supports up to 8 GB
of system memory with single channel DDR3L 1600MHz
SO-DIMM.
It implements an EHCI (Enhanced Host Controller Interface) compliant interface that
provides four USB 2.0 ports (two USB 2.0 ports at the rear panel and one 2*5-pin USB
2.0 header supports additional two USB 2.0 ports) and four USB 3.0 ports (two USB
3.0 ports at the rear panel and one USB 3.0 header supports additional two USB 3.0
ports).
The motherboard is equipped with advanced full set of I/O ports in the rear panel,
including one PS/2 Keyboard & PS/2 Mouse connectors, one D-sub (VGA) port, one
COM port,one HDMI port, two USB 3.0 ports, two USB 2.0 ports, one RJ45 LAN connec-
tor and audio jacks for line-in, line-out and microphone.
In addition, this motherboard supports two SATA 6Gb/s connectors for expansion.
Your motherboard package ships with the following items:
Package Contents
BSWI-D2 Motherboard
User Manual
DVD
I/O Shield
2 SATA Cables
Accessories may vary, please refer to actual goods you purchase.
