SoC Configuration
Scroll to this item and press <Enter> and view the following screen.
The chipset menu items allow you to change the settings for the SoC chip and other
system.
Chipset Menu
+/- :Change Opt.
Enter : Select
F1:General Help

Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.

:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version 2.17.1249. Copyright (C) 2015 American Megatrends, Inc.
SoC Parameters
SoC Configuration
TXE Information


Main Advanced Chipset M.I.B X Boot Security Exit
DVMT Pre-Allocated (64M)
This item is used to select DVMT 5.0 Pre-Allocated (Fixed) Graphics Memory size
used by the Internal Graphics Device.
DVMT Total Gfx Mem (256MB)
This item shows the information of DVMT 5.0 total graphic memory size used by
Internal Graphics Device.
Restore AC Power Loss (Power Off)
This item enables your computer to automatically restart or return to its operating
status.
+/- :Change Opt.
Enter : Select
F1:General Help

Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.

:Select Screen
:Select Item
F2:Previous Values
F3:Optimized Defaults
F4:Save & Exit
ESC:Exit
Version 2.17.1249. Copyright (C) 2015 American Megatrends, Inc.
Select DVMT 5.0 Pre-
Allocated (Fixed) Graphics
Memory size used by the
Internal Graphics Device.
Main Advanced Chipset M.I.B X Boot Security Exit
SoC Configuration
DVMT Pre-Allocated [64M]
DVMT Total Ffx Mem [256MB]
Restore AC Power Loss [Power off]
Audio Configuration
Azalia HD Audio [Enabled]
Azalia HDMI Codec [Enabled]
Case Open Warning [Disabled]
Chassis Opened [No]
