Using BIOS
ShutDown T
e
mperature (Disa
bled)
Ena
ble you to set the maximum te
mperature the system ca
n reach before powering
down.
Press <Esc> to return to the main menu setting page.
System Component Characteristics
These items display the monitoring of the overall inboard hardware health events,
such as System & CPU temperature, CPU & DIMM voltage, CPU & system fan
speed,...etc.
•
Vcore
•
V
DIMM
•
V
NB
•
VHT
•
CPU
F
AN
Speed
•
SYS F
AN
Speed
CPU T
emperature
•
44
46
