6
Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
LGA1155 socket for latest 2nd Generation Intel® Core™ Family
/ Pentium®/Celeron® Processors
2. CPU_FAN 4-pin CPU cooling fan connector
3. SYS_FAN 4-pin system cooling fan connector
4. DDR3_1,2 240-pin DDR3 SDRAM slots
5. ATX_POWER Standard 24-pin ATX power connector
6. SATA 6G 1, 2 Serial ATA 6.0 Gb/s connectors
7. SATA1~4 Serial ATA 3.0 Gb/s connectors
8. F_PANEL Front panel switch/LED header
9. F_USB1~2 Front panel USB 2.0 header (F_USB1 supports EZ Charger)
10. CASE CASE open header
11. ME_UNLOCK ME unlock header-for factory use only
12. CLR_CMOS Clear CMOS jumper
13. COM Onboard serial port header
14. SPK Speaker header
15. LPT Printer Header
16. TPM Trusted Platform Module header
17. SPDIFO SPDIF out header
18. F_AUDIO Front panel audio header
19. PCIE1 PCI Express x1 slot
20. PCI1~2 32-bit add-on card slots
21. PCIEX16 PCI Express slot for graphics interface
22. ATX12V 4-pin +12V power connector
1. CPU Socket
