4
Introducing the Motherboard
• LGA1155 socket for latest 2
nd
Generation Intel
®
Core
TM
Fam-
ily / Pentium
®
/ Celeron
®
processors
• Supports “Hyper-Threading” technology CPU
CPU
Specifications
• Intel
®
H61 Chipset
Chipset
• DDR3 memory architecture
• 2 x 240-pin DDR3 DIMM sockets support up to 16 GB
• Supports 1333/1066 DDR3 SDRAM
Memory
• 1 x PCI Express x16 Gen2 slot
• 1 x PCI Express x1 Gen2 slot
• 2 x PCI slots
• Supported by Intel
®
H61 Express Chipset
-4 x Serial ATA 3.0 Gb/s devices
• Supported by ASM1061 Chip
-2 x Serial ATA 6.0 Gb/s devices
Expansion
Slots
Storage
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin 12V Power connector
• 1 x 4-pin CPU_FAN connector
• 1 x 4-pin SYS_FAN connector
• 1 x Front Panel audio header
• 1 x Front Panel switch/LED header
• 1 x Speaker header
• 1 x SPDIF out header
• 4 x Serial SATA 3Gb/s connectors
• 2 x Serial SATA 6Gb/s connectors
• 2 x USB 2.0 headers support additional four USB 2.0 ports
(F_USB1 support EZ charger)
• 1 x Case open header
• 1 x TPM header
• 1 x Serial port header(COM)
• 1 x Parallel port header(LPT)
• 1 x CLR_CMOS header
Internal I/O
Connectors &
Headers
• 1 x PS/2 keyboard and PS/2 mouse connectors
• 1 x D-sub (VGA) port
• 1 x DVI port
• 1 x HDMI port
• 4 x USB 2.0 ports
• 1 x RJ45 LAN connector
• 2 x USB 3.0 ports (USB 2.0 optional)
• Audio jacks 6-ch for microphone, line-in and line-out
Rear Panel I/O
LAN
• Atheros AR8151 Gigabit Lan (Co-lay Atheros AR8152 10/
100 LAN)
• VIA VT1705 6-Ch HD audio CODEC
• Compliant with HD audio specification
Audio
