Using BIOS
PnP/ PCI Configurations
This section describes configuring the PCI bus system. PCI (Peripheral Component
Interconnect) is a system, which allows I/O devices to operate at speeds nearing
CPU’s when they communicate with own special components. All the options de-
scribes in this section are important and technical and it is strongly recommended
that only experienced users should make any changes to the default settings.
Menu Level
Item Help
Phoenix - AwardBIOS CMOS Setup Utility
PnP/PCI Configurations
x
f
Init Display First [PCI Slot]
Resources Controlled By [Auto(ESCD)]
IRQ Resources Press Enter
PCI/VGA Palette Snoop [Disabled]
**PCI Express relative items **
Maximum Payload Size [4096]
IRQ Resources (Press Enter)
In the IRQ Resources submenu, if you assign an IRQ to Legacy ISA, then that
Interrupt Request Line is reserved for a legacy ISA expansion card. Press <Esc> to
close the IRQ Resources submenu.
Resources Controlled By (Auto(ESCD))
You should leave this item at the default Auto (ESCD). Under this setting, the
system dynamically allocates resources to Plug and Play devices as they are required.
If you cannot get a legacy ISA (Industry Standard Architecture) expansion card to
work properly, you might be able to solve the problem by changing this item to
Manual, and then opening up the IRQ Resources submenu.
Maximum Payload Size (4096)
This item specifies the maximum payload size for the PCI Express function.
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
Press <Esc> to return to the main menu setting page.
PCI/VGA Palette Snoop (Disabled)
This item is designed to overcome problems that can be caused by some non-
standard VGA cards. This board includes a built-in VGA system that does not require
palette snooping so you must leave this item disabled.
Init Display First (PCI Slot)
This item allows you to choose the primary display card.
