ECS P49G Series User Manual

32
Motherboard User’s Guide
Press <Esc> to return to the Smart Fan Function page.
mnlk
: Move Enter : Select
+/-/: Value
F9: Load Default Settings
F1: General Help
F10: Save ESC: Exit
Options
Normal: auto adjusts
depending on the CPU
temperature.
Quiet: auto minimizes fan
speed for quiet
environment operation.
Silent: auto restricts fan
speed to make system
more quietly
.
Manual: the fan adjust
depending on user’s
parameter.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Smart Fan Function
Help Item
Smart Fan Function Enabled
SMART Fan Mode Quiet
SMART Fan start PWM value 28
CPU DeltaT +3
SMART Fan start Offset (-)32
Fan1 Slope PWM value/1 Unite 5
Fan1 Full Speed Offset(-) 7
mnlk
: Move Enter : Select
+/-/: Value
F9: Load Default Settings
F1: General Help
F10: Save ESC: Exit
Options
Normal: auto adjusts
depending on the CPU
temperature.
Quiet: auto minimizes fan
speed for quiet
environment operation.
Silent: auto restricts fan
speed to make system
more quietly.
Manual: the fan adjust
depending on user’s
parameter.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Smart Fan Function
Help Item
Smart Fan Function Enabled
SMART Fan Mode Silent
SMART Fan start PWM value 28
CPU DeltaT +3
SMART Fan start Offset (-)32
Fan1 Slope PWM value/1 Unite 5
Fan1 Full Speed Offset(-) 7
Press <Esc> to return to the Smart Fan Function page.
