ECS P49G Series User Manual

33
Chapter 3: BIOS Setup Utility
mnlk
: Move Enter : Select
+/-/: Value
F9: Load Default Settings
F1: General Help
F10: Save ESC: Exit
Options
Normal: auto adjusts
depending on the CPU
temperature.
Quiet: auto minimizes fan
speed for quiet
environment operation.
Silent: auto restricts fan
speed to make system
more quietly.
Manual: the fan adjust
depending on user’s
parameter.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Smart Fan Function
Help Item
Smart Fan Function Enabled
SMART Fan Mode Manual
SMART Fan start PWM value 28
CPU DeltaT +3
SMART Fan start Offset (-)32
Fan1 Slope PWM value/1 Unite 5
Fan1 Full Speed Offset(-) 7
Press <Esc> to return to the Smart Fan Function page.
Supports the latest PECI host technology. While using Core
TM
2 Quad or
Core
TM
2 Duo CPU which supports PECI, the original images of the BIOS
item “PC Health Status” and “Smart FAN Function” will be replaced by
PECI mode and negative number. (The max data from PECI is zero.)
mnlk
: Move Enter : Select
+/-/: Value
F9: Load Default Settings
F1: General Help
F10: Save ESC: Exit
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
PC Health Status
Help Item
-=- System Hardware Monitor-=-
Smart Fan Function Press Enter
CPU Fan Speed : 2509 RPM
CPU Vcore : 1.088 V
VDIMM : 1.824 V
-=- PECI Mode -=-
Offset to TCC Activation Temp. : -60
Press <Esc> to return to the PC Health Status page.
mnlk
: Move Enter : Select
+/-/: Value
F9: Load Default Settings
F1: General Help
F10: Save ESC: Exit
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Smart Fan Function
Help Item
SMART Fan Control Disabled
Disabled
Enabled
Options
