SE-3&SE-300 Series Electrocardiograph User Manual Settings
- 45 -
Chapter 8 Settings
Press the Up or Down or Left or Right arrow to select the function button, and then press the
MENU or PRINT/STOP to enter sub-window.
8.1 Work Mode
Item
Description
Mode Options
Including: AUTO, RHYT, R-R MANU, OFF-AUTO and OFF-RHYT.
Each item can be set to On. When set to On, it will be available on the
main screen, and you can press MODE/RST to switch to the mode.
In the MANU mode, you can press the lead switch button to switch the
lead group.
In the OFF-AUTO or OFF-RHYT mode, the electrocardiograph samples
ECG signal as well as save the patient record but doesn’t print ECG
report.
Display Style
Choose from: 3 channels, 6 channels and 12 channels, the default value
is 12 channels
Sampling Mode
(Only available in
the auto mode)
Choose from: Pre-Sample and Real-time, the default value is Real-time
Select Pre-Sample, 10s ECG data sampled before pressing the
PRINT/STOP key will be printed out.
NOTE: When Sampling Mode is set to Pre-Sample, if you press
the PRINT/STOP key before the electrocardiograph
samples for 10s, the recorder will not respond.

EDAN SE-3 Series Specifications

General

Paper Type	Thermal paper
Display	3.5 inch LCD
Leads	12-lead
Recording	Thermal printing system
Connectivity	USB
Power Supply	AC/Rechargeable Battery
Recording Mode	Automatic, Manual, Rhythm
Filters	AC, EMG, and Drift
Paper Size	80 mm
Battery	Rechargeable Li-ion battery
