C
HAPTER
2
| Installing the Switch
Connecting to a Power Source
– 40 –
CONNECTING TO A POWER SOURCE
To connect a device to a power source:
1. Insert the power cable plug directly into the socket located at the back of
the device.
Figure 12: Power Sockets
2. Plug the other end of the cable into a grounded, 3-pin socket.
3. Check the front-panel LEDs as the device is powered on to be sure the
Power LED is lit. If not, check that the power cable is correctly plugged in.
4. If you have purchased a Redundant Power Unit, connect it to the switch and
to an AC power source now, following the instructions included with the
package.
N
OTE
:
For International use, you may need to change the AC line cord.
You must use a line cord set that has been approved for the socket type
in your country.
