– 59 –
C SPECIFICATIONS
PHYSICAL CHARACTERISTICS
PORTS
48 10/100BASE-TX, with auto-negotiation
4 Combination Gigabit Ports (RJ-45/SFP)
NETWORK INTERFACE
Ports 1-48: RJ-45 connector, auto MDI/X
10BASE-T: RJ-45 (100-ohm, UTP cable; Category 3 or better)
100BASE-TX: RJ-45 (100-ohm, UTP cable; Category 5 or better)
Ports 49-52: RJ-45 connector, auto MDI/X
10BASE-T: RJ-45 (100-ohm, UTP cable; Category 3 or better)
100BASE-TX: RJ-45 (100-ohm, UTP cable; Category 5 or better)
1000BASE-T: RJ-45 (100-ohm, UTP cable; Category 5e or better)
BUFFER ARCHITECTURE
8 Mbits
AGGREGATE BANDWIDTH
17.6 Gbps
SWITCHING DATABASE
16K MAC address entries
LEDS
System:
Pwr (Power Supply), Diag (Diagnostic)
Port: Link/Activity
