Chapter 1
| Switch Description
Key Technical Specifications
– 13 –
Ground Point
The switch should be connected to ground using this screw connection. For more
information on how to connect ground to the switch, see “Grounding the Chassis”
on page 25.
Key Technical Specifications
The following table contains key system specifications for the switch.
Table 1: Key Technical Specifications
Item Specification
Ports 48 10/100/1000BASE-T RJ-45 ports with Auto-negotiation
4 Gigabit SFP transceiver slots
Network Interface Ports 1~48: RJ-45
◆
RJ-45 connector, auto MDI/X
Ports 49~52: SFP
◆
Gigabit SFP transceivers
Buffer Architecture 8 Mbits
Aggregate Bandwidth
104 Gbps
Switching Database 16K MAC address entries
LEDs System: Power, Diag (Diagnostic)
Ports 1~52:
Status (link, activity, speed)
AC Input Power ECS4110-52P: AC 100-240 V, 50-60 Hz, 7 A
ECS4110-52T: AC 100-240 V, 50-60 Hz, 1 A
Power Consumption ECS4110-52P: 65 W
ECS4110-52T: 530 W
Weight
ECS4110-52T: 3.14 kg
ECS4110-52P: 5.27 kg
Size (W x D x H):
ECS4110-52T: 44.0 x 28 x 4.4 cm (17.32 x 11.0 x 1.73 in)
ECS4110-52P: 44.0 x 37.9 x 4.4 cm (17.30 x 14.94 x 1.73 in)
Temperature Operating: 0° C to 50° C (32° F to 122° F)
Storage: -40° C to 70° C (-40° F to 158° F)
Humidity Operating: 10% to 95% (non-condensing)
Out-of-Band Management Front Panel RJ-45 console port
In-Band Management SSH, Telnet, SNMP, or HTTP
Software Loading HTTP, FTP/TFTP in-band
Forwarding Mode Store-and-forward
Throughput Wire speed
Flow Control Full Duplex: IEEE 802.3x
Half Duplex: Back pressure
