Chapter 5
| Port Connections
How to Install an SFP Transceiver
– 31 –
Figure 16: Inserting an SFP Transceiver into a Slot
Note:
To remove a transceiver: First disconnect the network cable, then pull the tab
to remove the transceiver from the slot.
SFP Transceiver
1
1
