– 29 –
5 Port Connections
This chapter focuses on making connections to switch network interfaces,
including how to install optional transceivers, and details on network cable
specifications.
The switch features ten 10/100/1000BASE-T RJ-45 ports and two Gigabit SFP
transceiver slots. The sections that follow describe these interfaces.
This chapter includes these sections:
◆ “Cable Labeling and Connection Records” on page 30
◆ “Understanding the Port Status LEDs” on page 31
◆ “How to Install an SFP Transceiver” on page 32
◆ “How to Connect to Twisted-Pair Copper Ports” on page 34
◆ “How to Connect to SFP Fiber Optic Ports” on page 38
