TABLE OF CONTENTS INTRODUCTION INSTALLATION OPERATING INSTRUCTIONS APPENDIX
Supplied Items Qty Required Tools
-Knife
-2 to 3 ft of wire (fi shing)
-Needle nose pliers
-Phillips screwdriver
-Flat tip screwdriver
-3/8” Drive Torque Wrench
-1/2” Wrench
-3/8” Drive Ratchet
-1/4” Socket
-5/16” Socket
-7/16” Deep Well Socket
-10mm Socket
-13mm Socket
-1/8” NPT Tap
-5/16” or 21/64” Drill Bit
1998.5 - 2002 5.9L (24V)
1 Main Wiring Harness...................(1)
2 Edge Juice Module.......................(1)
3 Adapters.......................................(1)
4 Zip Ties ......................................(10)
5 Hose Clamp..................................(1)
6 Brass Fitting.................................(1)
7 Leaded Fuse Link.........................(2)
8 Velcro Strips..................................(2)
9 Fuel Pressure Sensor....................(1)
10 Temperature Sensor......................(1)
11 EGT Probe...................................(1)
12 Banjo Bolt...................................(1)
13 Washer.........................................(2)
14 CS/CTS Kit.................................(1)
1
2 43
6 7
5
8
9 10 11
12 13
2000 (Data Link)
2001-2002 (MAP)
Note: Depending on your year of truck, you may not need everything provided.
14
REFER TO QUICK
INSTALL GUIDE
FOR INSTALL
