Edge Technologies V-65 Series - 2.2 Machine Dimensions; 2.3 Model Specifications

2. DATA OF TECHNIQUE V-65E-A
2-2
2.2 Machine size
2.3 Description
V-65E-A V-65LE-A
Diameter of bar
∅
5 mm ~
∅
65 mm
Length of bar
max.1250 mm
Bar length depends on
spindle length.
max. 1550 mm
Bar length depends on
spindle length.
Spindle height 850 mm ~ 1250 mm
Extend spindle height 1095 mm ~ 1500 mm
Weight 250 kg 280 kg
Air supply 5 ~ 7 kg / cm
2
Power supply 220 / 380V 0.4A 50 / 60Hz
