Portable Air Conditioner 2
Parts Identification
Back View
Front View
Handle
Front Control Panel
Front Grille / Air Intake
Exhaust
Drain
Power Cord
Caster
Front Air Vent
Note: You must open
the front air vent when
operating the unit. The
unit is designed to blow
air mostly from the right
side.
