2-2 SECTION 2: Specifications
3200-XS Sub-Bottom Profiling System User’s Manual Doc. No. 990-0000026-1000, Rev. 2.3
2.1.2 3200-XS Topside Processor
The specifications for the 3200-XS Topside Processor are shown in Table 2-2.
Table 2-2:
3200-XS Topside Processor Specifications
Mother board: Intel Pentium 4
Sonar Interface: Sonar Interface board (Tiger board) composed of Carrier board, Acquisition
board and Sonar/IDE board set
Memory: 512 MB RAM
Hard drives: 80 GB minimum (operating system)
160 GB minimum (data recording)
DVD-R/W drive: 10x4x32 minimum speed
Operating system: Windows XP
Application software: DISCOVER 3200SB
Display: High resolution 21-inch flat panel LCD monitor
Keyboard: High impact industrial
Trackball: High impact industrial
I/O ports: (1) Ethernet
(2) RS-232
(3) USB
(1) Parallel
Analog input: 16 bit resolution, 200 kHz max sampling rate
Analog output: 16 bit resolution, 200 kHz max sampling rate
Pulse type: Full Spectrum Chirp FM
Pulse length: 5–100 ms, depending tow vehicle and application
Bandwidth: 0.5–12 kHz, depending tow vehicle and application
Trigger in: TTL negative edge triggered
Trigger out: TTL negative edge triggered, 5 ms long pulse minimum
Sampling rate: 20, 25, 40, or 50 kHz, depending on the transmit upper frequency
Acoustic power: 212 dB re 1 µPa @ 1 meter peak (approx), at center frequency
Input voltage: 120–220 VAC, 50/60 Hz, auto sense
