Edgetech 3200-XS - Figure 3-1: Deck Unit Back Side

3-4 SECTION 3: Setup and Test 3200-XS Sub-Bottom Profiling System User’s Manual Doc. No. 990-0000026-1000, Rev. 2.3
Figure 3-1: Deck Unit Back Side
AC POWER SEA CABLE
connector
POWER AMP
POWER AMP
TOWFISH PREAMP
OUT TX2
OUT TX1
12 VDC OUT
PREAMP 5 VDC COMMON
indicator
indicator
TO PREAMP
test point
test pointtest point
GND
in/out connectors
PARALLEL
connector
MONITOR
connector
TRIGGER IN
connector
TRIGGER OUT
connector
connector
COM 1-NAV
POWER
SUPPLY
COM3
connector
ETHERNET
connector
USB
connectors
READY (left)
and Ping (right)
indicators
switch
