Edgetech 3200-XS

To Next Page

To Previous Page

Deck Unit Controls and Indicators 3-5

Figure 3-2: Deck Unit Front Side

TRACKBALL

connector

KEYBOARD

connector

HARD DISK

indicator

SYSTEM

indicator

POWER switch

Access panel (see

Figure 3-3 on page 3-6)

USB connector
