Connecting the System Components 3-9
Figure 3-4: A 75-Meter Kevlar Reinforced Tow Cable Shown Connected and Attached to
an SB-216S Tow Vehicle
Figure 3-5: Recommended Method for Dressing and Strain Relieving the Tow Cable
Cable grip
75-Meter Kevlar
Reinforced Tow Cable
Tow bridle
Tow vehicle
tow cable
Tie wrap
Shackle
Cable grip eyelet
connector
Stainless steel cable
for strain relief
Tow vehicle
tow cable
connector
Tow cable
connector
Tie wrap
Tow cable
Tow bridle
