APPENDIX A: Printer Connections
A number of different printers are available for connecting to the 3200-XS Sub-Bottom
Profiling System. All of these printers connect to the PARALLEL port connector on the back
of the Deck Unit (see “Deck Unit Connections” on page 3-7).
Of the available printers, the following are recommended for best results:
• Ultra 120 (and HD version) • EPC 1086 (early models)
• Ultra 200 (and HD version) • EPC 9206
• EPC HSP 100 • TDU-850
• EPC 1086-NT • Sys V8.5
• EPC 1086 • GeoPrinter 975
Of the available printers, the following are recommended for best results:
• EPC Model 1086
• EPC Model HSP-100
• Raytheon Model TDU-850
Listed in Table A-1 are the required settings to properly interface a printer with the 3200-XS
Sub-Bottom Profiling System.
Table A-1:
Printer Setting Requirements
Trigger: Internal
Data input: Parallel
Sweep: Forward
LPI: 200
Width: 2048
Data type: 6 bits
Shades: 64
Image: Positive
Contrast: 40%
