- 6 -
1-5 Familiar with your new wireless network card
1. USB Connector
2. Connector Cap (To protect USB connector when not in use)
3. Link/Activity LED
LED Name Light Status Description
On
Linked to a wireless access point /
Transferring data
Link /
Activity
Off No wireless activity
1
2
3
