MIDI Implementation
Model: V-8 Version: 1.00 Date: Jan. 10. 2008
Symbol Item Setting range
--------------------------------------------------------------------------------------------------------
n: MIDI channel 0H - FH (ch.1 - ch.16)
vv: Control value 00H - 7FH (0 - 127)
xx: Switch on and off 00H - 3FH (0 - 63): OFF
40H - 7FH (64 - 127): ON
--------------------------------------------------------------------------------------------------------
1. MIDI messages received at MIDI IN
* If MIDI Thru is ON, MIDI messages received at MIDI IN will be retransmitted
without change from MIDI OUT.
■
Channel Voice Massage
●
Note-on
Status
2nd byte 3rd byte
9nH kkH vvH
* Received only if Note Mode is ON.
* The input of each channel is selected. Ignored if a non-selectable note
message is received.
* The correspondence between note numbers and channels in 49Keys Mode
is shown below.
------------------------------------
Note No. Input
------------------------------------
24H A Ch.1
26H A Ch.2
28H A Ch.3
29H A Ch.4
2BH A Ch.5
2DH A Ch.6
2FH A Ch.7
30H A Ch.8
------------------------------------
32H B Ch.1
34H B Ch.2
35H B Ch.3
37H B Ch.4
39H B Ch.5
3BH B Ch.6
3CH B Ch.7
3EH B Ch.8
------------------------------------
●
Control Change
* By making settings in MIDI Setup, you can use these messages to control a
wide variety of things. The control changes that can be used “Settings
Transmitted/Received Using MIDI” (p. 96).
❍
Bank Select (controller numbers 0, 32)
Status
2nd byte 3rd byte
BnH 00H mmH
BnH 20H llH
mm, ll = bank number: 00 00H - 7F 7FH (bank.1 - bank.16384)
* Processing of a Bank Select message is suspended until a subsequent
Program Change is received.
* Bank Select data that is received will be maintained until a subsequent Bank
Select is received.
* This selects the input for each channel.
* Bank Select LSB will be ignored.
Controls correspond to bank select messages as follows.
--------------------------------------------------------------------------------------------------------
Bank Select Program No. Control
MSB | LSB
--------------------------------------------------------------------------------------------------------
50H | 00H (bank.10241) 00H - 07H MEMORY 1 - 8
--------------------------------------------------------------------------------------------------------
00H | 00H (bank.1) 00H - 07H Bus A INPUT 1 - 8
--------------------------------------------------------------------------------------------------------
01H | 00H (bank.129) 00H - 07H Bus B INPUT 1 - 8
--------------------------------------------------------------------------------------------------------
❍
Modulation (controller numbers 1)
Status
2nd byte 3rd byte
BnH 01H vvH
❍
Breath-type (controller numbers 2)
Status
2nd byte 3rd byte
BnH 02H vvH
❍
Foot-type (controller numbers 4)
Status
2nd byte 3rd byte
BnH 04H vvH
❍
Portamento Time (controller numbers 5)
Status
2nd byte 3rd byte
BnH 05H vvH
❍
Volume (controller numbers 7)
Status
2nd byte 3rd byte
BnH 07H vvH
❍
Balance (controller numbers 8)
Status
2nd byte 3rd byte
BnH 08H vvH
❍
Panpot (controller numbers 10)
Status
2nd byte 3rd byte
BnH 0AH vvH
❍
Expression (controller numbers 11)
Status
2nd byte 3rd byte
BnH 0BH vvH
❍
Effect Control 1 (controller numbers 12)
Status
2nd byte 3rd byte
BnH 0CH vvH
❍
Effect Control 2 (controller numbers 13)
Status
2nd byte 3rd byte
BnH 0DH vvH
❍
General Purpose Controllers 1–4 (controller numbers 16–19)
Status
2nd byte 3rd byte
BnH 10H -13H vvH
❍
Hold 1 (controller numbers 64)
Status
2nd byte 3rd byte
BnH 40H xxH
❍
Portamento (controller numbers 65)
Status
2nd byte 3rd byte
BnH 41H xxH
❍
Sostenuto (controller numbers 66)
Status
2nd byte 3rd byte
BnH 42H xxH
❍
Soft (controller numbers 67)
Status
2nd byte 3rd byte
BnH 43H xxH
❍
Legato (controller numbers 68)
Status
2nd byte 3rd byte
BnH 44H xxH
❍
Hold 2 (controller numbers 69)
Status
2nd byte 3rd byte
BnH 45H xxH
❍
Sound Controllers 1–10 (controller numbers 70–79)
Status
2nd byte 3rd byte
BnH 46- FH vvH
❍
General Purpose Controllers 5–8 (controller numbers 80–83)
Status
2nd byte 3rd byte
BnH 50 - 53FH vvH
❍
Portamento Control (controller numbers 84)
Status
2nd byte 3rd byte
BnH 54H vvH
❍
Effect Depth 2–5 (controller numbers 92–95)
Status
2nd byte 3rd byte
BnH 5C - 5FH vvH
