18. Specifications
SYSTEM RESOURCES
Main Processor 594MHz based CPU
Flash Memory 16 mbyte
DDR SDRAM 256 mbyte
Tuner/Front-end(Optional)
Tuner Type DVB-S / DVB-S2
Input Connector F-type, Connector, Female
Signal Level -65 to -25 dBm
Vertical: +13V
Horizontal: +18V
Current: Max. 400mA
LNB Power & Polarization
Overload Protection
22KHz Tone Frequency: 22±1KHz
Amplitude: 0.6±0.2V DiSEqC Control
Version 1.0, 1.1 1.2, USALS Available, unicable
Demodulation QPSK, 8PSK
Input Symbol Rate 1-45 Mbps, Convolution Code Rate
DVB-S 1/2, 2/3, 3/4 5/6, 7/8 Forward Error Correction (FEC)
DVB-S2 1/2, 3/5 , 2/3, 3/4 ,4/5 , 5/6, 8/9 , 9/10
Tuner Type DVB-T2/T/C
Input Connector IEC-type, Connector, Female
Frequency Range 47MHz~862MHz
Input Level -82.0dBm and -20.0dBm
Active ANT Power DC 5V at max 75 mA, Overload protection
Bandwidth VHF/UHF: 6MHz, 7MHz, 8MHz
Demodulation COFDM
Transmission mode(FFT) 1k, 2k, 4k, 8k normal and extended, 16k normal and extended, 32k normal
and extended.
Constellations QPSK, 16-QAM, 64-QAM, 256-QAM
Both rotated and non-rotated
Guard intervals 1/4, 19/256, 1/8, 19/128, 1/16, 1/32, 1/128
Code rate DVB-T: Viterbi + Reed Solomon 1/2, 2/3, 3/4, 5/6, 7/8.
DVB-T2: LPDC + BCH 1/2, 3/5, 2/3, 3/4, 5/6.
Scattered Pilot Pattern PP1, PP2, PP3, PP4, PP5, PP6, PP7, PP8
DVB-T2 Input Profiles Input Mode A-Signal PLP, input Mode B-Multiple PLPs(Common PLP, Type
1 and 2 up to the maximum allowed figure 255)
