EDM Solution 862 - Fault Analysis Mode; How To Determine The Type Of System Fault

Fault Analysis Mode
If a fault should occur, the FAULT or MAINS indicator will flash and the codepad will beep
once ever minute.
If the AC mains supply has failed, the MAINS indicator will flash until the AC mains supply
has restored. Pressing the # button once will acknowledge the fault and stop the codepad
from beeping once every minute.
How To Determine The Type Of System Fault
To determine all system faults other than the AC mains supply, enter fault analysis mode by
following the steps outlined below.
1. Hold down button 5 until two beeps are heard.
The FAULT indicator will remain steady and the STAY and AWAY indicators will
flash in unison with each other.
Any zone indicators displayed indicate the type of fault that has occurred. Refer to
Table 7: Fault Indicators on page 18 for the list of different system faults that may
occur.
2. To further determine the type of fault condition, you will need to hold down the button
that corresponds to the zone indicator displayed.
3. To exit fault analysis mode and return to the disarmed state, press the # button. The
FAULT indicator will remain displayed and the codepad will cease its once a minute
beep.
Zone
Indicator
Fault Description
1
Battery Fail
2
Date and Time
3
Sensor Watch
4
Horn Speaker Fail
5
Telephone Line Fail
6
E2 Fault
7
Fuse Fail
8
Communication Fail
Table 7: Fault Indicators
