Introduction 1-1
C h a p t e r
1
Chapter 1 Introduction
This reference manual is for the EDMI Atlas series of Energy Meters.
• Mk10 Three Phase Energy Meter (includes Mk10A)
• Mk10D Three Phase Energy Meter with Disconnect
• Mk7A Single Phase Energy Meter
• Mk7C Compact Single phase Energy Meter
• Mk10E High Performance Three Phase Energy Meter
It covers the hardware of the meter, including installation and connections.
The meter is fundamentally an energy meter, measuring the basic quantities of Wh, varh
and VAh. Consumption data may be recorded in a load survey, and as time of use data.
The meter can also measure a wide variety of instantaneous quantities. The
configuration is extremely flexible.
For information on configuring the meter and using it with the EziView software, see
the Atlas Software Reference Manual, 1910-E-07.
Using this Manual
Each chapter covers a specific meter type. While all Atlas meters share a common set
of functionality, the different meter types cover a broad range of metering applications.
Each hardware chapter stands on its own, and does not rely on the contents of other
chapters. The information on the LCD interface of all the meters is covered in Chapter
7 “LCD Display”.
Conventions Used in this Manual
All dates are in DD/MM/YY format.
References to settings or controls are printed in Italics.
